The hairline finish is a design finish in which the surface of the metal has a straight line of hair, like the straight hair of a lone woman.
This hairline finish is a general-purpose design finish that has been used for a long time.
The standard stainless steel hairline finish on the market is #180 to #240. It is a very simple finish but has been loved for many years.
The hairline finish can be expressed in a variety of ways by varying the roughness of the straight polished grain. It is also possible to create a derivative design finish called a cross hairline finish by crossing the grain. By processing in a circular shape, a circular hairline finish like that of a vinyl record can be created.
It is the most commonly used surface treatment for stainless steel in construction and equipment. It is also very versatile and is available in all thicknesses, widths, and lengths. Stainless steel grades such as SUS304 and SUS430 are available for almost all general-purpose materials.
There are two main types of manufacturing methods for stainless steel hairline finishes. For general-purpose plate thicknesses and sizes, stainless steel coils with hairline finishes are made in advance by steel manufacturers and supplied to coil centers in each region to be formed into plates. On the other hand, for special thicknesses or grades of steel, local polishers use their own hairline finishing manufacturing techniques to polish the coils. The difference is in the surface roughness and gloss. In the case of stainless steel hairline finish produced by steel manufacturers, the hairline finish is formed by the abrasive grain of the paper rotating in the polishing solution. On the other hand, at a local manufacturer, the paper is stationary or spinning slightly to form the grain. This difference affects the gloss and the depth of the grain. It is difficult to fine-tune the grain because steel manufacturers produce polish in large coils, but local polishers can adjust the grain. It is recommended that you choose the one that best suits your design and application.
It is relatively easy to modify the welded portions of the hairline finish or to modify the bending of sheet metal processing, but it can be made even easier by using paper with the same grain size as that used in the manufacture of stainless steel hairline finish sheets.
Product information
- Grade: 201, 304, 304L, 430
- Process: Hot rolled and Cold rolled
- Type: Sheet, Plate, Coil, and Strip
- Polish:#180 – #240, No.4
- Width:500-2000mm or customize
- Length:1000-6000mm or customize
- Thickness:Cold Rolled:0.3-3mm,Hot Rolled:3-20mm
- Standard:ASME,ASTM,EN,GB,DIN,JIS,etc.
Chemical analysis
Tensile and Hardness Requirement
Available Stock Dimension for Hairline Finish Stainless Steel Sheet
- Delivery:15 to 20 days according to your order quantity
- Shipping: FCL, LCL, Buck ship
- Loading Port: Shanghai, Ningbo
- Packing: wooden case, fixed with steel strip, then wrapped with woven bags
Our Advantage
1. Annual production capacity:50,000 Metric Ton
2. With at least 80 tons of stock for general specification
3. Quote within 12 hours
4.2 hours drive to the nearest seaport
5. Delivery maximum 10 days for stock
We are the Hairline Finish Stainless Steel Sheet manufacturer, If you are interested in our company and products, welcome to consult through online consultation, hotline, E-mail, and other ways.We are dedicated to providing you with high-quality and efficient service.
