Heat Resistant TP310S TP310H TP310 Stainless Steel Tube Pipe Seamless Type SCH40 SCH80
| Products Name | TP310S Stainless Steel Pipe |
| Pipe Type | Seamless Pipe . Welded Pipe |
| Surface | Pickling , polishing |
| Out Diameter | 6 - 508mm |
| Wall Thickness | 1.0 - 50.0mm |
| Length | 6m or cutting any length as request |
| Standard | ASTM / GB / EN / DIN / JIS / BS / BIS |
| Mainly Grade | 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy |
| Service | Cutting, Polishing, Hairline Finishing |
| MOQ | 200 Kgs |
| Packing | standard packing for export |
| Application | Industrial , food , medical, househould |
310S 310H Stainless Steel Tubes Properties and Character
ASTM A213 / ASME SA 213 TP 310S TP 310H TP 310, EN 10216 – 5 1.4845 Stainless Steel Pipe is typically used for elevated temperature applications. Its high chromium and nickel content provides comparable corrosion resistance, superior in oxidation resistance, and the retention of a larger fraction of room temperature strength than the common austenitic Alloy 304. 310S Stainless Steel Tube is an austenitic heat resisting alloy with excellent resistance to oxidation under mildly cyclic conditions to 2100°F. Its high chromium and nickel contents provide comparable corrosion resistance, superior resistance to oxidation and the retention of a larger fraction of room temperature strength.
Benefits of Using ASME SA213 TP310S TP310H Stainless Steel
310S Stainless Steel Pipe is a highly alloyed austenitic stainless steel used for high temperature application. The high chromium and nickel content give the steel excellent oxidation resistance as well as high strength at high temperature. This grade is also very ductile, and has good weldability enabling its widespread usage in many applications.
Typical Applications Grade 310/310S is used in fluidised bed combustors, kilns, radiant tubes, tube hangers for petroleum refining and steam boilers, Stainless Steel Reheater Tubes and Superheater Tubes for Boiler, coal gasifier internal components, lead pots, thermowells, refractory anchor bolts, burners and combustion chambers, retorts, muffles, annealing covers, saggers, food processing equipment, cryogenic structures.
310S Stainless Steel combining excellent high temperature properties with good weldability and ductility, is designed for high temperature service. 310S stainless steel resists oxidation in continuous service at temperatures up to 1150°C provided reducing sulfur gases are not present. 310S is also used for intermittent service at temperatures up to 1040°C.
ASTM A213 TP310S Stainless Steel Pipe Tubes Sizes
ASTM A312 TP310S Seamless Pipes / ASTM A213 ASME SA 213 TP310S TP310H TP310 Seamless Tubes
- Size: 6NB – 1200NB
- OD: 1/8″ – 12″ NPS
- Wall Thickness : 0.6 – 63.5mm
- Length: Fixed Length, Double Random & Cut Length
ASTM A312 A249 TP310S ERW / Welded Pipes
- Size: 1/8″ – 36″ NB, 1/4″ – 36″ OD
- OD: 6.35 -508 mm
- Wall Thickness : 0.8 – 63.5mm
- Length: up to 25 Meters
ASME SA213 TP310S TP310H EN10088-1 1.4841 Chemical Composition
| Grade | UNS Designation | C | Mn | P | S | Si | Cr | Ni |
| | S31002 | 0.02 max | 2.0 max | 0.020 max | 0.015 max | 0.15 max | 24.0 – 26.0 | 19.0 – 22.0 |
| 310S | S31008 | 0.08 max | 2.0 max | 0.045 max | 0.030 max | 1.00 max | 24.0 – 26.0 | 19.0 – 22.0 |
| 310H | S31009 | 0.04-0.10 | 2.0 max | 0.045 max | 0.030 max | 1.00 max | 24.0 – 26.0 | 19.0 – 22.0 |
| 1.4841 | | 0.20
max | 2.0 max | 0.045 max | 0.015 max | 1.50-2.50 | 24.0 – 26.0 | 19.0 – 22.0 |
ASME SA213 TP310S TP310H Stainless Steel Mechanical Properties
1. 310S Stainless Steel Pipe Mechanical Properties at Room Temperature
| TP310H | TP310H | TP310S | TP310S |
| | Typical | Minimum | Typical | Minimum |
| Tensile Strength, MPa | 645 | 515 | 595 | 515 |
| Yield Stress (0.2 % offset), MPa | 355 | 205 | 295 | 205 |
| Elongation (Percent in 50mm) | 52 | 35 | 52 | 35 |
| Hardness (Rockwell) | – | 90 HRB Max | – | 90 HRB Max |
2. 310S Stainless Steel Tubes Properties at Elevated Temperatures
The values quoted are those for 310.
Enquire for data on 310S .
Short Time Elevated Temperature Tensile Strength
| Temperature, °C | 550 | 650 | 750 | 850 | 950 | 1050 |
| Tensile Strength, MPa | 550 | 430 | 280 | 180 | 90 | 50 |
TP310S TP310H Stainless Steel Tubes Standard Specifications
310S is the low carbon version of 310 and is suggested for applications where sensitisation, and subsequent corrosion by high temperature gases or condensates during shutdown may pose a problem. Our 310S 310H is manufactured in accordance ASTM A 213 / ASME SA213, ASTM A312 / ASME SA312.
ASTM A213 / ASME SA213 Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A167 ASME SA167 Standard Specification for Stainless and Heat-Resisting Chromium-Nickel Steel Plate, Sheet, and Strip
ASTM A312 / ASME SA312 Seamless and welded austenitic stainless steel pipes
EN 10216-5 1.4845 Seamless steel tubes for pressure purposes
| Alloy | UNS Designation | Werkstoff NR. | Specifications* |
| 310S | S31008 | EN 10216 – 5 1.4845 | A/SA249, A/SA312, A/SA213 |
| 310H | S31009 | EN 10216 – 5 1.4845 | A/SA249, A/SA312, A/SA213 |
ASME SA213 TP310S Stainless Steel Tubes and Pipes Application
310S 310H have wide application in all high-temperature environments where scaling and corrosion resistance, as well as high temperature strength and good creep resistance, are required
310S Stainless Steel Pipe Applications Oven linings, Stainless Steel Reheater Tubes and Superheater Tubes for Boiler, boiler baffles, kilns, lead pots, radiant tubes, annealing covers, saggers, burners, combustion tubes, refractory anchor bolts, fire box sheets, furnace components and other high temperature containers.
