Precision Stainless Steel Strips 17-4PH / 630 / 1.4542 Stainless Steel Roll 0.1 - 3.0mm

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Precision Stainless Steel Strips 17-4PH / 630 / 1.4542 Stainless Steel Roll 0.1 - 3.0mm

Brand Name : TISCO

Model Number : 200Series 300 Series 400 Series C276 904L,Monel 400 K500

Certification : ISO

Place of Origin : China

MOQ : 2 Ton

Price : 2400 - 3500 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : stainless steel strip

Thickness : 0.1 - 3.0mm

Width : within 1500mm

MOQ : 1000 kgs

Grade : 200 series 300 series 400 series , nickel alloy

Surface : BA 2B NO.4 HL 8K NO.1

Standard : ASTM EN GB JIS

Packing : wooden frame and water proof paper

Contact Now

Precision Stainless Steel Strips 17-4PH / 630 / 1.4542 Stainless Steel Roll 0.1 - 3.0mm

17-4PH Stainless Steel Foil Specifications

Product Name 17-4PH Stainless Steel Foil
Grades 17-4PH/630
Hardness 170HV-430HV or as customers’ requests
Thickness 0.02mm-0.1mm
Width 1.0mm-650mm
Edge Slit/Mill
Quantity Tolerance ±10%
Paper Core Internal Diameter Ø500mm paper core, special internal diameter core and without paper core on customer request
Surface Finish NO.1/2B/2D/BA/HL/Brushed/6K/8K Mirror,etc
Packaging Wooden Pallet/Wooden Case
Payment Terms 30% TT deposit and 70% balance before shipment, 100% LC at sight
Delivery Time 5-7 working days
MOQ 100Kgs
Shipping Port Shanghai/Ningbo port
Sample The sample is available

Description

Alloy 1.4542 is a structurally hardened martensitic stainless steel which combines a hardness of about 48 HRC with good corrosion resistance.
This grade has a hardening peak at 480°C which allows easy ageing after machining on an initially solution treated condition. The grade is remelted to improve the cleanliness and homogeneity of the material.

Stainless has a number of sources in stock, as well as different formats or states of the product to suit your processing needs.

This product can also be custom made or cut into slugs by our service centres.

Main applications

Due to its good resistance to corrosion, its good hardness in the treated state (48HRC) and its resilience, the grade is used in particular in the manufacture of instruments for the medical sector (drills, etc.), in general mechanics, in the food industry and in the automotive sector.

Metallurgy

The manufacturing processes associated with the transformation processes make it possible to obtain a homogeneous microstructure. In the treated state, the microstructure consists of martensite and nanometric intermetallic precipitates (Ni3Cu) which germinate during ageing.

Precision Stainless Steel Strips 17-4PH / 630 / 1.4542 Stainless Steel Roll 0.1 - 3.0mmPrecision Stainless Steel Strips 17-4PH / 630 / 1.4542 Stainless Steel Roll 0.1 - 3.0mmPrecision Stainless Steel Strips 17-4PH / 630 / 1.4542 Stainless Steel Roll 0.1 - 3.0mmPrecision Stainless Steel Strips 17-4PH / 630 / 1.4542 Stainless Steel Roll 0.1 - 3.0mm

Machinability

Forgeability
The grade can be hot forged in the 900/1250°C temperature range. Resolving will be necessary to achieve maximum hardness.

Weldability
The grade can be welded using most processes. Welding should preferably be done before ageing to avoid embrittlement of the heat affected zone.

Typical heat treatments

Corrosion resistance

The grade has very good corrosion resistance but must be passivated. The microstructure contains little or no chromium carbides, which makes it less susceptible to intergranular corrosion.

Standard Sizes

Round or flat bars annealed (Condition A or AT) or pre-treated. Surface ground or peeled depending on diameter
Flat bars made to measure in the annealed condition (consult us)
Other format : sheets , Pipe, Coil, Bars
