Cold Drawn Precision Stainless Steel Strips 17-4PH / AISI630 Stainless Steel Roll And Band

Name: Cold Drawn Precision Stainless Steel Strips 174PH AISI630 Stainless Steel Roll And Band
Brand: TISCO
Price: 2400 USD

Wholesale Cold Drawn Precision Stainless Steel Strips 17-4PH / AISI630 Stainless Steel Roll And Band from china suppliers

Brand Name : TISCO

Model Number : 200Series 300 Series 400 Series C276 904L,Monel 400 K500

Certification : ISO

Place of Origin : China

MOQ : 2 Ton

Price : 2400 - 3500 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : stainless steel strip

Thickness : 0.1 - 3.0mm

Width : within 1500mm

MOQ : 1000 kgs

Grade : 200 series 300 series 400 series , nickel alloy

Surface : BA 2B NO.4 HL 8K NO.1

Standard : ASTM EN GB JIS

Packing : wooden frame and water proof paper

Contact Now

17-4PH High Hardness Stainless Steel Strip Coils SS Roll Thickness 0.1 - 3.0mm Cold Rolled 2B BA 2D Surface

17-4PH Stainless Steel Foil Specifications

Product Name	17-4PH Stainless Steel Foil
Grades	17-4PH/630
Hardness	170HV-430HV or as customers’ requests
Thickness	0.02mm-0.1mm
Width	1.0mm-650mm
Edge	Slit/Mill
Quantity Tolerance	±10%
Paper Core Internal Diameter	Ø500mm paper core, special internal diameter core and without paper core on customer request
Surface Finish	NO.1/2B/2D/BA/HL/Brushed/6K/8K Mirror,etc
Packaging	Wooden Pallet/Wooden Case
Payment Terms	30% TT deposit and 70% balance before shipment, 100% LC at sight
Delivery Time	5-7 working days
MOQ	100Kgs
Shipping Port	Shanghai/Ningbo port
Sample	The sample is available

17-4PH is a well-established precipitation hardening martensitic stainless steel capable of achieving very high strength and hardness after a relatively simple heat treatment. It offers excellent corrosion resistance combined with a structured range of mechanical property levels depending on the precise heat treatment applied.

The materials can be readily machined and fabricated in the softer tempers and can then be heat-treated to exceptional strength and dimensional stability. 17-4PH is widely used in the chemical, petrochemical, offshore, paper, and aerospace industries making best use of its outstanding corrosion resistance, wear resistance, strength and hardness.

Main fields of application of 17-4PH/ AISI630

Surgical and dental instrument, screwdriver.

17- 4 retains a high strength of precipitation hardening stainless steels a majority of applications are within the aerospace sector and OAG applications

Valves and engine components
Turbine blades
Gears
Shafts
Aircraft structures

17-4PH Stainless Steel Foil Chemical Compositions

The chemical components of grade 17-4PH stainless steel foil is summarized in the following table:

C	Si	Mn	P	S	Cr	Ni	Cu	Nb
0.07 max	1.00 max	1.00 max	0.040 max	0.030 max	15.00~17.50	3.0~5.0	3.0~5.0	0.15~0.45

Heat treatment

Alloy 17-4PH is provided in the solution-annealed condition (Condition A). Mechanical properties may be improved by subsequent age hardening treatments. These aging treatments are commonly described as conditions H900, H1025, H1075, H1150, H1150M and H1150D.

Mechanical Properties

Condition	UTS	0.2% Yield	Elongation	Reduction of area	Hardness Brinel
H900	190.000	170.000	10	40	388
H1025	155.000	145.000	12	45	331
H1075	145.000	125.000	13	45	311
H1150	135.000	105.000	16	50	277
H1150m	115.000	75.000	18	55	255
H1150-D	125.000	105.000	16	50	255
