UNS N06625 Seamless Tubing Aerospace, Chemical & Marine Grade

Name: UNS N06625 Seamless Tubing Aerospace Chemical amp Marine Grade
Brand: DELTA
Price: 40 USD

Wholesale UNS N06625 Seamless Tubing Aerospace, Chemical & Marine Grade from china suppliers

Brand Name : DELTA

Model Number : inconel 625

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 40-45 USD/Kg

Payment Terms : L/C, T/T, Western Union

Supply Ability : 3 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Nickel alloy Pipe

Grade : inconel 625

Diameter : DN10 - DN300

Length : 6m or custom cutting any length as request

Standard : ASTM EN

Service : Cutting

Loading Port : Shanghai Port

Thickness : 0.5 - 40.0mm

Contact Now

UNS N06625 Seamless Tubing – Aerospace, Chemical & Marine Grade

Products Specification

Model	Nickel Tubes Pipes
Material Grade	Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc
Diameter	a) Capillary Tube Outer Diameter: 0.2mm-6.mm Welding Tube Outer Diameter: 6.mm- 840mm Seamless Tube Outer Diameter: 6mm-630mm
	b) Capillary Tube Wall Thickness: 0.02mm-2mm Welding Tube Wall Thickness: 0.5-150mm Seamless Tube Wall Thickness: 0.5-60mm
	c) Length: ≤500mm Or in coil
Tolerance	a) Outer Diameter: +/- 0.01mm
	b) Thickness: +/- 0.01mm
	c) Length: +/- 0.1mm
Surface Treatment	Polishing,Annealing, Bright, Pickling
Type	Welded,Seamless
Shape	Round,Square,Irregular
Application	medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.

ALLOY 625 SEAMLESS NICKEL PIPE

Alloy 625 nickel pipe is made from a nickel-chromium-molybdenum alloy with an addition of niobium. High strength and toughness from cryogenic temperatures to 1800°F. Good oxidation resistance, exceptional fatigue strength, and good resistance to many corrosives.

Typical applications include chemical processing, aerospace and marine engineering, pollution control equipment, and nuclear reactors.

ASTM B444 SEAMLESS NICRMONB INCONEL 625 AND NICRMOSI ALLOY PIPE & TUBE

Chemical Composition (wt.%) of ASTM B444 Seamless Inconel 625 Alloy Pipe and Tube

UNS No.

(Ni) (%)

(Cr) (%)

(Fe) (%)

(Mo) (%)

(Nb) (%)

(Ta) (%)

(Al) (%)

(Ti) (%)

(Co) (%)

(Mn) (%)

(Si) (%)

(P) (%)

(S) (%)

N06625

58.0 min

20.0-23.0

5.0 max

8.0-10.0

3.15-4.15

–

0.4 max

–

0.1 max

0.5 max

0.015 max

N06852

58.0 min

22.0-24.0

5.0 max

9.0-11.0

–

0.2 max

0.6 max

–

0.03 max

0.5 max

0.015 max

0.01 max

N06219

52.5 min

20.0-23.0

2.0 max

9.0-10.5

–

0.5 max

0.15-0.60

0.50 max

0.040 max

1.0 max

0.50 max

0.030 max

Mechanical Properties of ASTM B444 Seamless Inconel 625 Alloy Pipe and Tube

Alloy	Tensile Strength (MPa)	Yield Strength (0.2% Offset) (MPa)	Elongation (%)
UNS N06625	760 min	345 min	30 min
UNS N06852	880 min	620 min	30 min
UNS N06219	1100 min	760 min	25 min

Packing

Small Diameter Pipes and Tubes:

End treatment: Beveled or plain ends are capped or plugged with plastic protectors.
Bundling: Smaller diameter pipes and tubes are grouped in bundles.
Protection: Bundles are then covered with seaworthy bags to protect against moisture and damage during transport.
Alternative packaging: Small-diameter pipes can also be loosely packed in plywood boxes instead of bundled in bags for specific needs or handling requirements.

Large Diameter Pipes:

End treatment: Similar to small diameters, beveled or plain ends are likely capped or plugged.
Loose packing: Larger diameter pipes are individually packed and not bundled due to their size and weight.
Protection: Each pipe is covered with a seaworthy bag to protect against the elements and potential damage during shipping.

Application

Chemical Processing: Nickel-chromium-molybdenum-niobium alloys are commonly used in chemical processing plants with critical corrosion resistance. They can withstand corrosive chemicals, acids, and high temperatures.
Oil and Gas Industry: These alloys are utilized in various applications within the oil and gas industry, including downhole tubing, production tubing, and piping systems for offshore platforms. Their resistance to corrosive environments and high temperatures makes them suitable for these demanding conditions.
Aerospace: Nickel-chromium-molybdenum alloys find applications in the aerospace industry due to their high strength, corrosion resistance, and ability to withstand extreme temperatures. They are used in aircraft engines, exhaust systems, and other components subjected to high heat and corrosive environments.
Nuclear Industry: These alloys’ excellent resistance to corrosion and high temperatures make them suitable for use in nuclear power plants. They are used in steam generator tubing, reactor vessels, and piping systems.
Marine Applications: In marine environments where corrosion from seawater is a concern, nickel-chromium-molybdenum alloys are used for piping, tubing, and other components. Their corrosion resistance and high-strength properties make them ideal for offshore platforms, shipbuilding, and marine equipment.
Power Generation: These alloys are also used in power generation plants, mainly when corrosion resistance and high temperatures are essential. They can be found in boilers, heat exchangers, and other components of power generation systems
