Heat-Resistant 304H SS Plate For Furnace Components Pressure Vessels Annealed Pickled Surface

Brand Name : TISCO BAOSTEEL

Model Number : 304H / S30409

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 1700- 2000 USD/Ton

Payment Terms : T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Stainless Steel Plate

Grade : 304H / S30409

Thickness : 3.0 - 80.0mm

Width : 1500mm 1800mm 2000mm

Surface : NO.1

Brand : BAOSTEEL TISCO

Standard : ASTM A240/240M

Loading Port : Shanghai Port

Contact Now

Heat-Resistant 304H SS Plate For Furnace Components & Pressure Vessels Annealed & Pickled Surface

Products Specification

Products Name 304H Stainless Steel Plate
Main Grades Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc
Thickness 3.0 - 80.0mm
Width 1250mm,1500mm ,1800mm,2000mm, or custom other size as request
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT
Type of Material Laser Cutting
Form Plate / coil
Test Certificate Yes.
Finish NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA.
Brand TISCO, LISCO,BAOSTEEL , POSCO, JISCO

Introduction​
304H stainless steel plate is a high - performance austenitic stainless steel material, which is an upgraded version of the commonly used 304 stainless steel. The "H" in its name stands for "high carbon", indicating that its carbon content is increased compared to 304 stainless steel. This higher carbon content endows it with enhanced strength and creep resistance at elevated temperatures, making it an ideal choice for applications that require high - temperature stability and durability. It also maintains excellent corrosion resistance in a variety of environments, including resistance to oxidation, pitting, and intergranular corrosion, similar to 304 stainless steel.​
Parameters​
  • Chemical Composition:​
  • Carbon (C): 0.04 - 0.10%​
  • Chromium (Cr): 18.0 - 20.0%​
  • Nickel (Ni): 8.0 - 10.5%​
  • Manganese (Mn): ≤2.00%​
  • Silicon (Si): ≤0.75%​
  • Phosphorus (P): ≤0.045%​
  • Sulfur (S): ≤0.030%​
  • Mechanical Properties:​
  • Tensile Strength: ≥515 MPa​
  • Yield Strength (0.2% offset): ≥205 MPa​
  • Elongation at Break: ≥40%​
  • Hardness (Rockwell B): ≤92​
Specifications​
  • Thickness: Typically ranges from 0.3 mm to 100 mm.​
  • Width: Commonly available in widths of 1000 mm, 1219 mm, 1500 mm, 1800 mm, 2000 mm.​
  • Length: Standard lengths include 2000 mm, 2438 mm, 3000 mm, 6000 mm, and can also be customized according to customer requirements.​
Standards​
304H stainless steel plate complies with international and domestic standards, such as ASTM A240/A240M (American Society for Testing and Materials), EN 10088 - 2 (European standard), and GB/T 24511 (Chinese national standard). These standards ensure the quality, chemical composition, and mechanical properties of the material, making it suitable for a wide range of industrial applications.​
Similar Grades​
  • ASTM/ASME: 304​
  • EN Standard: X6CrNi18 - 10​
  • JIS Standard: SUS304H​
  • GB Standard: 07Cr18Ni9​
Applications​
  • Petrochemical Industry: Used in the construction of reactors, heat exchangers, and pipelines due to its excellent resistance to high - temperature and corrosion - prone environments.​
  • Power Generation: Applied in boiler components, steam pipes, and superheaters where high - temperature strength and corrosion resistance are required.​
  • Automotive Industry: Utilized in exhaust systems and engine components to withstand high - temperature and corrosive conditions.​
  • Food and Beverage Industry: Due to its non - toxic and corrosion - resistant properties, it is suitable for manufacturing food processing equipment, storage tanks, and conveyor belts.​
  • Architectural and Decoration: Employed in building facades, handrails, and decorative elements for its aesthetic appeal and durability.​
Processing Services​
  • Cutting: Precision cutting services are available, including shearing, laser cutting, and plasma cutting, to meet various size requirements of customers.​
  • Bending: Professional bending services can form the 304H stainless steel plate into different shapes according to design specifications, such as U - shaped, V - shaped, or circular bends.​
  • Polishing: Provide surface polishing treatments, including mechanical polishing and electrochemical polishing, to achieve different surface finishes, from matte to mirror - like.​
  • Welding: Our experienced welders are proficient in various welding techniques, such as TIG welding, MIG welding, and spot welding, ensuring strong and reliable joints for fabricated products.​
  • Custom Fabrication: We offer comprehensive custom fabrication services, from design to production, to meet specific project requirements, including the manufacture of complex components and assemblies.
